These universal high quality sending units feature an all stainless steel design (including diaphragm) and are designed to be used in a wide variety of situations where accurate pressure measurement are required. Perfect for screwing straight into AN8 ORB fuel pressure regulators ( Turbosmart AN8), fuel rails etc.
Great for fuel pressure, oil pressure, manifold pressure, etc
**Connector is not included.
Features include:
- 0 to 150 Psi positive pressure window
- Stainless 316L body and diaphragm
- Male AN8 ORB Thread
- 24mm Hex
- No internal rubber O-rings
- Includes a Delphi 3 pin connector
- 0.5 to 4.5 V Linear output
- Laser welded
- Compatible all pump fuels, methanol, E85, Ethanol, oil, hydraulic fluids, water, coolant, etc
Note: Remote mounting of these sensors is recommended as direct engine vibration will cause premature failure and void the warranty. This means the sensor cannot be mounted to anything that is directly attached to the engine (fuel rails, oil block adapters, etc). They can be mounted on oil filter relocators, fuel pressure regulators, etc. when isolated from the engine by hoses.
Stainless Steel Pressure Sensor 150Psi (0 to 150 Psi) AN8 ORB with Connector
SKU: 133-017
BRAND: EFI Solutions
Rated 4/5 based on 1 review.
AU$98.77
Incl. GST
SAVE AU$5.20 (5%)
10+ In Stock
Stainless Steel Pressure Sensor 150Psi (0 to 150 Psi) AN8 ORB with Connector
AU$98.77
Incl. GST
10+ In
Stock
These universal high quality sending units feature an all stainless steel design (including diaphragm) and are designed to be used in a wide variety of situations where accurate pressure measurement are required. Perfect for screwing straight into AN8 ORB fuel pressure regulators ( Turbosmart AN8), fuel rails etc.
Great for fuel pressure, oil pressure, manifold pressure, etc
**Connector is not included.
Features include:
- 0 to 150 Psi positive pressure window
- Stainless 316L body and diaphragm
- Male AN8 ORB Thread
- 24mm Hex
- No internal rubber O-rings
- Includes a Delphi 3 pin connector
- 0.5 to 4.5 V Linear output
- Laser welded
- Compatible all pump fuels, methanol, E85, Ethanol, oil, hydraulic fluids, water, coolant, etc
Note: Remote mounting of these sensors is recommended as direct engine vibration will cause premature failure and void the warranty. This means the sensor cannot be mounted to anything that is directly attached to the engine (fuel rails, oil block adapters, etc). They can be mounted on oil filter relocators, fuel pressure regulators, etc. when isolated from the engine by hoses.
| SKU | 133-017 |
| Brand | EFI Solutions |
| Shipping Weight | 0.0900kg | MPN: | SS208 3/4UNF A03A06 |
Stainless Steel Pressure Sensor 150Psi (0 to 150 P
By: Simon Coulter on 29 September 2021Mated to the end of my Radium fuel rail which has an AN8 ORB female fitting. Ideally I only needed a 100psi sensor but most of them came with NPT fittings so I would have needed an adapter. This was the only AN8 ORB pressure sensor I could find and, unlike NPT fittings, it screwed all the way into the AN8 ORB fuel rail which makes for a better/stronger mechanical connection (needed because the sensor is quite long and relatively heavy - not suited for NPT connector).
