Features:

• Dual Channel High Current H-Bridge Outputs
• 2 x Wastegate Valve Position Inputs (0-5v)
• 2 x Wastegate Temperature Inputs (0-5v)
• 2 x Frequency Inputs (Advanced Wastegate Position Encoder)
• PWM Target Position Input
• Analog 0-5v Position Target
• CAN Bus Position Demand Target
• CAN Bus Valve Area Target
• CAN Bus Programmable PID Mode Option
• Factory Loaded PID Calibration for all Turbosmart eGates
• Internal Over-Current Protection
• Internal Over-Temp Protection
• Auto Position Calibration
• Anodized Aluminium Housing
• 34 Pin Superseal Connector
